Free shipping IR Infrared Obstacle Avoidance Sensor Module for Arduino Smart Car Robot 3-wire Reflective Photoelectric New

Module Description

The sensor module adaptable to ambient light, having a pair of infrared emitting and receiving tubes, transmitting tubes emit infrared certain frequency, when the direction of an obstacle is detected (reflection surface), the infrared reflected is received by the reception tube, After a comparator circuit processing, the green light is on, but the signal output interface output digital signal (a low-level signal), you can adjust the detection distance knob potentiometer, the effective distance range of 2 ~ 30cm, the working voltage of 3.3V- 5V. Detection range of the sensor can be obtained by adjusting potentiometer, with little interference, easy to assemble, easy to use features, can be widely used in robot obstacle avoidance, avoidance car, line count, and black and white line tracking and many other occasions.
Module Parameters
When the module detects an obstacle in front of the signal, the green indicator lights on the board level, while the OUT port sustained low signal output, the module detects the distance 2 ~ 30cm, detection angle 35 °, the distance can detect potential is adjusted clockwise adjustment potentiometer, detects the distance increases; counterclockwise adjustment potentiometer, reducing detection distance.
2, the sensor active infrared reflection detection, target reflectivity and therefore the shape is critical detection distance. Where the minimum detection distance black, white, maximum; small objects away from a small area, a large area from the Grand.
3, the sensor module output port OUT port can be directly connected to the microcontroller IO can also be directly drive a 5V relay; Connection: VCC-VCC; GND-GND; OUT-IO
4, comparators LM393, stable;
5, the module can be 3-5V DC power supply. When the power is turned on, the red power indicator lights;
6, with the screw holes 3mm, easy fixed installation;
7, board size: 3.2CM * 1.4CM
8, each module has been shipped threshold comparator voltage adjusted by potentiometer good, non-special case, do not adjustable potentiometer.
Module Interface Description
1 VCC 3.3V-5V external voltage (can be directly connected to 5v and 3.3v MCU MCU)
2 GND GND External
3 OUT small board digital output interface (0 and 1)

CALL FOR PRICE

Price: $0.00

5PCS 3.7V lithium polymer battery 351743 200MAH point reading pen recorder small toys wireless headphones

olymer 3.7V lithium polymer battery with protection board
Nominal Voltage : 3.7V

Charging voltage : 4.2V

Main features:

1 , high discharge platform , the average voltage exceeds 3.7V, low resistance , fast charge time

2 , good security , with over charge protection, over -discharge protection, over current protection

3, the protection IC technology parameters : Overcharge protection voltage 4.20V 0.05V

4 , over- discharge protection voltage 2.7V 0.1V

5 , over- current protection 3.0 1.0A (2.7V ~ 4.25V)

6 , the discharge temperature : -20 C ~ +60 C

7 , the protection IC parameters : Overcharge protection voltage 4.20V 0.05V, over-discharge protection voltage 2.7V 0.1V
8 , high voltage, high energy density
9 , long cycle life , high safety
10 , shape , size, spiritual words
11 , self-discharge, pollution

12 Application : MP3/MP4, Bluetooth / GPRS / GPS mobile phone , PDA, small toys , digital cameras and cameras and other digital products .

Main features:

A variety of sizes : Model and capacity to choose from, applicability

(2) Quality guarantee: A product batteries , high capacity , low internal resistance

3 stable performance : long cycle life : 500 continuous charge and discharge , the battery capacity is not less than 80 % of the rated capacity.

4 No memory effect : any time to charge and discharge

5 Safety: built-in circuit protection board s has no fire in short circuit , overcharge , over discharge , shock, vibration , acupuncture , heat, and other states , no explosion and so on.

Note:

Battery Handling Precautions: prohibit the use of a s object to touch the foil packaging materials, not bend the top edge, not open or destroy the hems , pole bending ears fragile ban prohibiting drop impact bending battery , short circuit or reversed at any time prohibit the positive negative battery .

Other matters : to prevent a short circuit within the battery pack strictly prohibited remove the battery , the battery in a fire is prohibited , prohibited the battery immersed in liquid ( such as: water, drinks , juice, coffee ) , shall be replaceable battery , prohibit the use of a damaged battery .

Our all products are the real power standard, the specific use of a long long time , to look at the machine consumes oh we can to ensure that the pro is a new article , but more likely to have scratches polymer lithium battery , does not affect the use of mind Oh ~ Do not shoot the

CALL FOR PRICE

Price: $0.00

BUK7611-55A BUK7611 55A TO-263 IC Chip

CALL FOR PRICE

Price: $0.00

Smart Electronics HX1838 Infrared Remote Control Module IR Receiver Module DIY Kit HX1838 for Arduino Raspberry Pi

1 VCC external 3.3V-5V voltage (can be directly connected with the 5V MCU and 3.3V chip)

2 GND external GND

3 IN external microcontroller I/O port, I/O port has been designed with 10K pull-up resistor

Theoretical test suite from 5-8 meters, but the surrounding environmental factors depends on when you use the actual application and intermediate barrier (e.g. diaphragm, glass, hinder the barrier or other materials), receiving head using HX1838, with a power indicator light, can receive the 38K frequency of any remote control coding data!

CALL FOR PRICE

Price: $0.00

Kuman Project Complete Starter Kit with Tutorial for Arduino UNO R3 Mega 2560 robot Nano breadboard Kits

This is an upgraded Super Starter Kit with free PDF tutorial(23 lessons), developed specially for those beginners who are interested in arduino
Update version:The kit has 44pcs components With tutorial in a CD including project introduction and source code,add More modules:LED Thermistor Touch sensor module than old version.
The UNO R3 board 1602 LCD display with pin header (no need to be soldered by yourself) HC-SR04 Ultrasonic 5V Relay Power Supply Module Servo Motor 9V Battery with DC Prototype Expansion Board are included
A complete set of most common and useful electronic components for arduino clear listing in a nice Plastic package
Detailed tutorials including project introduction CAN BE PROVIDED FOR FREE,contact us BY Email to get document

CALL FOR PRICE

Price: $0.00

Electronic components on request

Electronic components

we bring to our customers request. Make your inquiry or order and we will contact you to take your order

Quality and best price. Wholesale or retail

China manufacturers of Electrical components and Electronics meet the highest standards of quality, performance and delivery. You can discover our large selection of electronic components, electrical equipments, and electrical engineering products.

ccomponents2

Arduino – Raspberry Pi – Components and packs

71comhj6mfl-_sl1000_

lcd-touch-7-cable-hdmi-raspberry-pi-pantalla-tactil

Contact

Your Name (required)

Your Email (required)

Subject

Your Message

Price: $0.00

NOTEBOOK ASUS 15.6″ Intel Core i3

Asus 15.6″ X540LA-SI30205P Laptop Intel Core i3 4GB Memory 1TB Hard Drive Silver

Read the rest of this entry »

Price: $267.30

NOTEBOOK HP Core I5 17″

HP 17.3″ Pavilion Flagship High Performance Laptop- Intel Core i5-4210U, 4GB RAM, 1TB HDD, HD+ Display (1600 x 900), DVD/CD Burner, HDMI, Webcam, WIFI, Windows 10, Silver

Read the rest of this entry »

Price: $359.10
